The 50-250mm PVC pipe production line is about to be completed

This line is composed of conical twin screw extruder, Vacuum calibration tank, haul-off(take-off) machine ,motors, cutter and stacker etc.

The extruder and haul off methods are two-claw,three-claw four-claw,six-claw,eight-claw,ten-claw,twelve claw etc. You may choose saw blade cutting type or planetary cutting type. It is aditionaly attached with length counter and intensifying device. This line with reliable performance and high production eficiency.

Our company can also manufacture special pipe production lines,e.g. spiral silencing pipe and core foaming pipe according to your requirements.

Plastic PVC pipe making machine is used to produce UPVC/PVC pipe with diameter from 16 up to 800mm, which is used for electric conduit, building drainage, sewage pipe, water supply pipe, well casing pipe, agricultural irrigation pipe and so on.

It's mainly composed by conical twin screw extruder, mould, vacuum calibration tank, haul off machine, cutting machine, stacker, belling machine.

By changing dorn or mould lip, it can produce several diameter or wall thickness on same machine.

Main features

1. Ensuring long-time stable operation & long service life

2. Compact structure, low noise, high bearing capacity, high transmission efficiency, ensuring long-time stable operation

3. Heating is controlled by Solid State Relay (S.S.R), realizing stable heating; (SSR) no spark & no noise improve safe production.

4. Siemens PLC controlling system with reliable technology, automatic and intelligent functions for centralized control and monitoring extrusion lines, which helps easy operation.

Anxing machinery Plastic pipe machine for water supply electric conduit pipe

Conical double screw extruder for plastic PVC pipe

The line is mainly used in producing pipe with PPR resin materials also used in PB PPC PE resin pipe material production .

PLC control,high degree of automation

Adopting special and good effect screw

Adopting compound spiral head,effectively deleting memory function of the material

Vacuum calibration,constant temperature control,eliminating pipe stress

Adopting Co-extrusion head to make the tube with color line

High extrusion capacity,low melt temperature,uniform melt temperature

Wide processing range of raw materials

Advantages

1. The extruder of HDPE pipe line adopt high efficiency screw & barrel, the gearbox is hardening teeth gearbox with self-lubrication system. The motor adopt Siemens standard motor and speed controlled by ABB inverter. The control system adopts Siemens PLC control or button control.

2. This PE pipe line is composed by material charger+ Single screw extruder + pipe mold + vacuum calibration tank + spraying cooling tank x 2sets + three pedrail haul-off machine + no-dust cutter+ stacker.

3. The tank body of vacuum calibration tank adopt two chamber structure the vacuum calibration and cooling parts. Both of vacuum tank and spraying cooling tank adopt stainless steel 304#. The excellent vacuum system ensures the precise sizing for pipes; spraying cooling will improve the cooling efficiency; Auto water temperature control system make the machine more intelligent.

4. The haul-off machine of this pipe line will adopt caterpillars type. With meter code, it can count the pipe length during the production. Cutting system adopt no-dust cutter with PLC control system.
