Good Qulaity Double Wall Corrugated Pipe Machine

High density polyethylene/polyvinyl chloride double wall corrugated pipe manufacturing machine

Double wall corrugated water pipe production line

The Good Qulaity Double Wall Corrugated Pipe Machine adopts extrusion molding technology, which has the characteristics of reliable quality and high efficiency. Compared with other plastic pipe wall structures, the double wall corrugated pipe has excellent wall structure design, and its lightweight achieves lower production costs, improving market competitiveness. This pipe is widely used in various fields as a replacement for concrete and iron pipes, due to its excellent features such as easy connection and installation of accessories, and reliable quality.

Characteristics of production line structure

1. Two high-efficiency co extrusion single screw extruders

2. Adopting excellent screw and new groove sleeve design, the extruder has the following advantages: high plasticization rate, smooth melt, stable production process, and the ability to use different materials for the inner and outer layers of the pipeline

3. The corrugated forming block is made of special alloy material. It has high precision, high strength, and excellent heat dissipation performance.

4. Nitrogen treatment on the surface of the mold. There is a wall thickness adjustment device in the mouth mold, which can produce pipes of different raw materials.

5. It has an expansion function, which can reduce investment and improve efficiency.

6. The production line adopts advanced Siemens PLC control system, with human-machine interface operating system, high degree of automation, and easy operation.

Extruder: Adopting a conical twin-screw extruder, the uniquely designed screw achieves short plasticizing time, good compounding, and excellent plasticization.

Transmission: Equipped with high-quality gearboxes and reducers, it has a beautiful appearance, smooth operation, low noise, and long service life.

Squeezing cylinder temperature control system: using stainless steel cover cast aluminum heater and air cooling system to ensure good cooling and heating functions, precise temperature control.

Screw and barrel: The screw core is equipped with an internal temperature control system, and the barrel is equipped with a vacuum degassing system to remove exhaust gases from the raw materials, ensuring high product quality.

Drive system: using A C motor, using Fuji or ABB frequency converter, can provide stable torque output and various speeds.

Vacuum calibration tank: It has two vacuum chambers to ensure the perfect roundness of the pipeline. It is cooled by water spray and equipped with a temperature controller to achieve automatic water discharge. The tank body is made of stainless steel and has a long service life.

Towing machine: Provides 2 laws, 3 claws, 4 claws, 6 claws, and 8 claws to manufacture various pipelines, with towing speed controlled by FUJI or ABB inverters.

Cutting units: saw cutting and planetary saw cutting, with dust collection system.

Stacking unit: automatic overturning system, can freely fix the length of the pipeline.

Control system: manual control cabinet or Siemens PLC touch screen control
